PK series

PK-GRSM-B2

PK-GRSM-B2

Features

  • 16 - speed - range milling head.
  • NT40# spindle taper.
  • Extra wide table working area 54" x 10".
  • 5HP powerful motor.
  • Hardened and ground X,Y axes and table surface.
  • Specifications
  • Accessories
MODEL PK-GRSM-B2
Table 1372 x 254 mm
T-Slot (width x number x distance) 28 x 3 x 16
Rapid Feed Rate 890 mm/min
TRAVEL
Longitudinal 900 mm
Cross 380 mm
Vertical 380 mm
Spindle Travel 127 mm
Arm Travel 520 mm
SPINDLE
Taper NT 40#
Spindle Nose to Table Surface 80-483 mm
Spindle Center to Column 180-515 mm
Spindle Spindle Low Range Low 60, 95, 150, 225
High 535, 825, 1320, 1930
High Range Low 120, 195, 305, 450
High 1055, 1640, 2620, 3820
Quill Feeds Per. Rev. of Spindle 0.04 - 0.08 - 0.15 mm
Main Motor 3.7 KW 3PH
Swivel Angle to Right & Left 90°
Swivel Angle to Front & Back 45°
Approximate Net Weight 1450 Kgs

All Specifications And Designs Are Subject To Change Without Notice.

Standard Accessories
  • Drawbar
  • Way Chip Protector
  • Tool Box with Tools
Options
  • Cooling Pump System (Opt.)
  • Chip Tray (Opt.)
  • Halogen Worklight (Opt.)
  • Power Feed for X Axis (Opt.)
  • Power Feed for Y Axis (Opt.)
  • Rapid Motor for Knee Elevation (Opt.)
  • Electric control box with operation panel (Opt.)
